John Deere Gator XUV 825i

  Daily Weekly Monthly
Reg
$245
$850
$2,550
Corp
$210
$775
$2,490
+ Delivery Rate & Operator Rate
We honor the lowest rate on all long term rentals.

John Deere XUV 825i Utility Vehicle

Get through almost any kind of terrain with the John Deere XUV 825i crossover utility vehicle. It has a heavy-duty truck style frame that utilizes a precision-engineered drivetrain system that fully uses all the engine's power. It has optimized accelaration, towing, hill climbing and hauling capabilities. This cross over utility vehicle rental will get the job done, whether its work or play. Drive visitors around your construction site, festival or film set quickly, easily and comfortably with the John Deere 825i XUV rental from Wescan!

The engine of the John Deere 825i cross over utility vehicle rental offers the following performance and reliability features: 4-cycle gas, electronic fuel injection engine. 812 cc and 50 hp (37 kw) @ 6000 rpm.

  • Excellent Terrain Capability: Performance is no problem with the 825i XUV rental. Engine power is fully used with the precision drive train system. Variable speed drive transmits power through the clutch system to the transaxle.
  • Top Speed: 71-km/h
  • Power: Great at any altitude and can start in -20 degrees (f). Electronic ignition is continuously variable for optimum engine power and provides fast, reliable starts. Also, overhead valve design provides greater efficiency and fuel economy. Fuel capacity is 27.6 litres (7.3 U.S. gal).
  • Suspension: The John Deere 825i XUV rental has a full independent front and back dual A-arm suspension with adjustable coil. The back suspension has a sway bar.
  • Optimal Cargo/Storage Space: Large durable cargo box for transporting goods and materials. It's 46 inches long, 52 inches wide and 11 inches deep. The cargo cab of the 825i XUV rental can hold up to 1000 lb. (454 kg). The dump angle is 47 degrees.
  • Dimensions: Wheelbase: 2007 mm (78 in). Dry weight: 747.9 kg (1649 lb). Length: 2946 mm (116 in). Width: 1571 mm (61 in). Height: 1903 mm (75 in).
  • Towing Capacity: The John Deere 825i rental has a towing capacity of 680 kg (1500 lb).

Wescan rentals delivers and maintains heavy equipment, earthmovers, excavators, skid steers, track loaders and attachments. We service the Lower Mainland of Greater Vancouver, Fraser Valley and Vancouver Island: Vancouver, Burnaby, Poco, Port Coquitlam, Port Moody, Surrey, White Rock, Langley, New Westminster, Delta, Coquitlam, Ladner, Tsawwassen, Richmond, North Vancouver, West Vancouver, Pitt Meadows, Maple Ridge, Mission, Abbotsford,Chilliwack, Whistler, Victoria, Nanaimo. Contact us for more details on our rental packages.

Engine and Electrical

Type 4-cycle gas, Electronic Fuel Injection (EFI)
Cylinders 3
Valving Dual Overhead Cam (DOHC)
Horsepower* 50 (37 kw)* @ 6000 rpm
Displacement 812 cc
Maximum torque, ft.-lb. (Nm) 47 @ 3200 rpm
Iginition type Solid state 12V
Lubrication Full pressure
Oil filter Screw on filter
RPM, idle (no load) 1125 +/- 75
RPM, fast (no load) Electronically controlled
Cooling system Liquid
Air cleaner Dry replaceable single element w/remote intake
Muffler Spark-arresting
Battery 340CCA
Alternator 75 amp @ 6000 rpm, regulated, 900 watts
Headlights Two 37.5 watt halogen

Fuel System

Capacity, U.S. gal. (L) 7.0
Consumption (half load at avg. speed), U.S. gal./hr. (L/h) ---
Fuel pump type Electric

4WD

System Type On-demand true four-wheel drive system
Front Differential (Engagement) Auto-locking (on/off rocker switch)
Rear Differential (Engagement) Positive locking, mechanically actuated (hand-operated)

Transmission

Type Continuously Variable Transmission (CVT) with clutch enclosure & engine braking
Drive belt Spun top cog, 31 mm wide
Ground speed, mph (km/h) 0-44 hi forward, 0-17 lo forward, 0-20 reverse
Transaxle Two speed, oil bath
Gear Selection Forward (hi-lo), netural, reverse
Overall Reduction Ratio: ---
Low 86.8488:1
High 42.1430:1
Reverse 75.9333:1
Brakes Front/rear hydraulic disk
Park brake Driveline mechanical disk, hand operated
Bearings Sealed, double-row ball
Axle 27 mm dia., forged CV-shaft with double offset joint

Suspension and Steering

Suspension, front Fully independent dual A-Arm with adjustable coils
Front Susp. Travel (total), in. (mm) 8
Suspension, rear Fully independent dual A-Arm with adjustable coils and sway bar
Rear Susp. Travel (total), in. (mm) 9
Steering Rack and pinion
Turning radius, ft. (m) 12.4

Hitch

Front Standard 2-in receiver
Rear Standard 2-in receiver

Occupant Protective System (OPS)

Tubular overhead structure 1.75 steel tube
Passenger grab handles Front OPS post, front dash
Seat belts 3-point seat belts
Certification SAE J2194 and OSHA ROPS

Ground Pressure (Max)

With 200-lb. Operator Only, psi (kg/cm2) 14
Fully Loaded Vehicle, psi (kg/cm2) 14

Ground Clearance

Ground Clearance, in. (mm) 11
Under Foot Platform, in. (mm) 12.25

Dimensions

Length (w/out bumper), in. (mm) 116
Length (with bumper), in. (mm) 116
Width, in. (mm) 62
Front-tread Centers, in. (mm) 51.2
Rear-tread Centers, in. (mm) 51.2
Height (overall with OPS), in. (mm) 75
Wheelbase, in. (mm) 79
Weight (incl. fuel/fluids), lb. (kg) 1640
Seating Capacity 2
Seat Type Standard high back, bucket (tilts forward) or bench seat / optional Performace high back seats
Towing Capacity, lb. (kg) 1500
Payload Capacity, lb. (kg) 1400
Sound rating (at operator's ear), dB(A) 89.4

Cargo Box

Material Polypropylene side panels and tailgate; steel floor and load guard
Capacity ---
Dimensions, in. (mm) 45L x 52W x 12D
Volume, cu. ft. (m3) 16.4
Weight, lb. (kg) 1000
Dump Manual with lift assist shock (factory installed power lift option)
Tailgate Hinged at bottom, removable

Tires

Front 26x9-12 Ancla M-T (extreme terrain); 25x9-12 Terrahawk AT (all terrain)
Rear 26x11-12 Ancla M-T (extreme terrain); 25x11-12 Terrahawk AT (all terrain)
Turf & AT489 ---
All Trail II ---
Available Tread Types ----
